Specifications:
- Operating voltage: 4.8 V a 7.2 V
- Running Current 500 mA – 900 mA (6V)
- Stall Current 2.5 A (6V)
- Temperature range: 0 °C – 55 °C
- Control System: Analog
- Operating Angle: 180degree
- Required Pulse: 900us-2100us
- Direction: CCW
- Operating speed: 0.17 s/60º (4.8 V), 0.14 s/60º (6 V)
- Dead band width: 5 μs
- Wire length: 30cm
- Connector: 3 pin ‘S’ type female header
- Weight: 55 g
- Dimension: 40.7 x 19.7 x 42.9 mm approx.
- Stall torque: 9.8 kgf·cm (4.8 V ), 11 kgf·cm (6 V)
